SB070022024 – MCP3202T-BI/SN 12BIT ADC SCHEMATIC BLOCK

This schematic block features the MCP3202T-BI/SN, a 12-bit Analog-to-Digital Converter (ADC) from Microchip Technology, designed for precision data acquisition applications. Offering two input channels and a successive approximation register (SAR) architecture, it achieves sampling rates of up to 100 ksps while maintaining low power consumption.

The MCP3202 communicates via a serial peripheral interface (SPI), making it simple to integrate with a wide range of microcontrollers and embedded systems. Packaged in an 8-pin SOIC, it provides a compact solution for systems requiring reliable and accurate analog-to-digital conversion.

Delivered as a Quickboards schematic block, this ADC allows engineers to rapidly prototype data acquisition systems with a reference-ready design, ensuring consistent performance and reducing development time.

Key Features:

• 12-bit SAR ADC with 2 input channels
• Up to 100 ksps sampling rate
• SPI digital interface for easy MCU integration
• Compact 8-pin SOIC package
• Low power consumption for portable devices
• Quickboards schematic block for rapid prototyping

Typical Applications:

• Data acquisition and logging systems
• Sensor interfacing in embedded designs
• Portable and battery-powered devices
• Industrial monitoring and measurement
• Consumer electronics and IoT devices

By using this Quickboards schematic block, engineers can accelerate development, reduce integration risk, and build on a proven reference design powered by the MCP3202 12-bit ADC.
