A technical schematic for a 8-channel Active High Pass Filter. The page features six identical active filter circuits arranged in two columns, labeled VIN1 through VIN6. Each circuit utilizes an MCP601T op-amp with varying capacitor and resistor values to achieve specific -3dB cutoff frequencies ranging from 1 Hz to 10 MHz.

SB090082025 – MCP601T-I/OT ACTIVE HIGH PASS FILTER SCHEMATIC BLOCK

MCP601T-I/OT — 8CH ACTIVE HPF

SKU: SB090082025 Categories: ,
Primary IC

MCP601T-I/OT
IC Datasheet

https://ww1.microchip.com/downloads/en/DeviceDoc/21314g.pdf
Associated Hardware

HB090082025
