A technical schematic for a 8-channel Passive High Pass Filter. The page features six identical active filter circuits arranged in two columns, labeled VIN1 through VIN6. Each circuit utilizes an RC circuit with varying capacitor and resistor values to achieve specific -3dB cutoff frequencies ranging from 1 Hz to 10 MHz.

SB090022025 – PASSIVE HIGH PASS FILTER SCHEMATIC BLOCK

MCP601T-I/OT — 8CH PASSIVE HPF

SKU: SB090022025 Categories: ,
Primary IC

MCP601T-I/OT
IC Datasheet

https://ww1.microchip.com/downloads/en/DeviceDoc/21314g.pdf
Associated Hardware

HB090022025
